EATON XTCE072D00C | BH8XTX

EATON XTCE072D00C IEC Magnetic Contactor, Non-Reversing, 3 Poles, 72 A, 480 VAC Coil, D Frame Size

Item: BH8XTX Model: XTCE072D00CCross Ref: 21EP05
In Stock

Get it by Tuesday, Jun 17

Free Shipping Eligible. Free shipping is applicable on orders over €150 and products weighing less than 5 kg. Products exceeding 5 kg will incur the default shipping charges.

€644.78 /unit
Add To Cart
Request a Quote

Payment

Delivery

Product Specifications:

ItemContactor
Amps Rating72A
Coil Voltage412-480/415-480V AC
Contact Configuration0 NO, 0 NC
Continuous Amps Rating72A
Frame Size55 mm
Frequency50/60 Hz
Frequency Rating50-60 Hz
Height5.55"
Length4.65"
Max. Hp Rating5, 10, 15/ 20, 25, 50, 60 hp (1/3 Phase @ 115, 200, 230/200, 230, 460, 575V)
Mfr. SeriesXT IEC Series
NotesScrew Terminals (6-65A), 5 mm (80-150A), No Lugs (185-2000A)
Number Of Poles3
OperationNon-Reversing
Product NameEaton XT IEC contactor
TerminalsScrew Terminals
TypeFull Voltage Non-reversing Contactor
Warranty1 yr.
Width2 19/25"
Auxiliary Contacts IncludedNone
Contactor StyleIEC
Electrical Operating Durability300 (AC-4 400V Ie), 800 (AC-1 400V Ie), 800 (AC-3 400V Ie)
Full Load Current - Inductive72A
Full Load Current - Resistive98A
Horsepower @ Single Phase - 120v Ac5 hp
Horsepower @ Single Phase - 240v Ac15 hp
Horsepower @ Three Phase - 208v Ac20 hp
Horsepower @ Three Phase - 240v Ac25 hp
Horsepower @ Three Phase - 480v Ac50 hp
Horsepower @ Three Phase - 600v Ac60 hp
Includes Auxiliary ContactsNo
Integrated Surge SuppressionYes
Ip RatingIP20
Main Power Pole Contact Form3NO
Maximum Operating Temperature122°F
Maximum Voltage Rating690V AC
Mechanical Operating Durability10000000
Minimum Operating Temperature-13°F
Nema Enclosure RatingNo Enclosure
Nominal Coil Voltage @ 60hz480V AC
Overall Depth4.65"
Overall Height5.55"
Overall Width2 19/25"
Reversing CapabilityNon-Reversing
SeriesXT Series
StandardsCE, CSA, EN 60947, IEC 60947, ROHS, UL LISTED
Wire Termination TypeScrew

Shipping Info:

Ship weight (kg) 2.8035
Ship height (cm)14.1
Ship length (cm)11.81
Ship width (cm)7.01
Country of OriginDE

Product Variants

ProductModelNumber Of PolesFrame SizeHeightHp @ 3 Phase - 240vHp @ 3 Phase - 480vHp @ 3 Phase - 575vHp @ 3 Phase - 208vHp @ 1 Phase - 240vPrice
EATON XTCE007B01A | BH8XAG XTCE007B01A345 mm2"-----€181.80
EATON XTCE007B01C | BH8XAL XTCE007B01C3-3 1/2"-----€160.82
EATON XTCE007B01E | BH8XAV XTCE007B01E3-3"-----€160.82
EATON XTCE007B01B | BH8XAW XTCE007B01B345 mm3.07"-----€181.80
EATON XTCE007B01T | BH8XAZ XTCE007B01T3-1 1/2"-----€181.80
EATON XTCE007B01TD | BH8XBA XTCE007B01TD3-3"-----€241.16
EATON XTCE007B10A | BH8XBC XTCE007B10A345 mm2.67"-----€171.16
