| Item | Multi-Gas Detector |
| Alarm Setting | Adjustable |
| Alarm Type | Audible/Vibrating/Visual |
| Battery Type | Lithium Ion |
| Depth | 1.703" |
| Detects | Carbon Monoxide, Combustible Gases, Hydrogen Sulfide, Oxygen |
| Display | LCD |
| Features | (24) Sensor Options Including PID And IR |
| Gas Type | CO, H2S, LEL, O2 |
| Height | 5.297" |
| Housing Color | Black |
| Includes | Charger |
| Operating Temp. Range | +4°F to +122°F |
| Sensor Range | 0% v/v to 5% v/v, 0% lel to 100% lel, 0 ppm to 1500 ppm, 0 ppm to 500 ppm, 0% v/v to 30% v/v |
| Width | 3.047" |
| Accuracy | +/-0.5^5% (At Temperature of Calibration), +/-0.8^5% (Over Full Measurement Temperature), +/-15% (Over Full Measurement Temperature), +/-5% (0.0 to 200.0 ppm) +/-15% (200.1 to 500.0 ppm) (At Temperature of Calibration), +/-5% (At Temperature of Calibration) |
| Alarm Setting Adjustment | Adjustable Alarm Setting |
| Alarm Volume Level | 95 dB |
| Alert Type | Light, Sound, Vibration |
| Battery Chemistry | Lithium Ion |
| Battery Life | 36 hrs. |
| Brand & Series | INDUSTRIAL SCIENTIFIC MX6 iBrid |
| Data Logger | Yes |
| Display Screen Type | LCD |
| Display Type | Digital |
| Gas Detected | Carbon Monoxide, Hydrogen Sulfide, LEL, Oxygen |
| Hazardous Location Specification | Class I Divisions 1 |
| Housing Material | Stainless Steel |
| Includes Charger | Yes |
| Includes Mounting Hardware | Yes |
| Includes Pump | No |
| Ip Rating | IP64 |
| Manufacturer Warranty Length | Limited Lifetime |
| Maximum Operating Humidity | 95% |
| Maximum Operating Temperature | 131°F |
| Measurement Range | Carbon Monoxide (0 ppm to 1500 ppm), Hydrogen Sulfide (0 ppm to 500 ppm), Oxygen (0% vol to 30% vol) |
| Minimum Operating Humidity | 15% |
| Minimum Operating Temperature | -4°F |
| Number Of Gases Detected | 3 |
| Number Of Sensors | 2 |
| Overall Depth | 1.9" |
| Overall Height | 5.3" |
| Overall Width | 3 1/2" |
| Power Source | Battery |
| Product Type | Multi-Gas Detector |
| Rechargeable Battery | No |
| Replaceable Battery | Yes |
| Resolution | Carbon Monoxide 1% vol, Hydrogen Sulfide 0.1% vol, Oxygen 0.1% vol |
| Sensor Type | Infrared, Photo Ionization |
| Series | MX6 iBrid |
| Standards | ANZEX: EX IA S ZONE 0 I, EX IA S ZONE 0 IIC T4, ATEX: EX IA I, ATEX: EX IA IIC T4 GA, CL II, GROUPS F G, CL L ZONE LEL 0, AEX IA D IIC T4 (OR AEX IA D IIC T4 IR SENSOR), CMA: APPROVAL FOR MINING PRODUCTS, CH4, O2, CO, CO2, CSA: CL I, GR A-D T4, EAC: PBEXIADI X, 1EXIADIICT4 X, EQUIPMENT GROUP AND CATEGORY: I M1/II 1G, EX D IA IIC T4, EX D IA IIC T4 GB, EX IA IIC T4 GA, IECEX: EX IA I (EX IA D I IR SENSOR), II 1G (OR EX D IA IIC T4 GB IR SENSOR), INMETRO: EX IA IIC T4 GA, KC: EX D IA IIC T4, KIMM: |
| Temperature Code | T4 |
