SQUARE D B1.45 Thermal Unit 1.02 - 1.27a | AF6PHZ 1H604

SQUARE D B1.45 Thermal Unit 1.02 - 1.27a

Item: AF6PHZ Model: B1.45Cross Ref: 1H604
In Stock : 136 Units

Get it by Friday, Jun 13

€61.20 /unit
Add To Cart
Request a Quote

Payment

Delivery

Product Specifications:

ItemThermal Unit
Fl Amp @ 1-ph/ Dp 20-30a/ Standard Enclosure1.02A
Fl Amp @ 1-ph/ Dp 40a/ Standard Enclosure1.27A
Fl Amp @ 1-ph/ Man. Size 0/ Open & Large Enclosure1.23A
Fl Amp @ 1-ph/ Man. Size 0/ Standard Enclosure1.14A
Fl Amp @ 1-ph/ Man. Size 1/ Open & Large Enclosure1.23A
Fl Amp @ 1-ph/ Man. Size 1/ Standard Enclosure1.14A
Fl Amp @ 1-ph/ Size 00,0,1/ Open & Large Enclosure1.1A
Fl Amp @ 1-ph/ Size 00,0,1/ Standard Enclosure1.05A
Fl Amp @ 1-ph/ Size 1p/ Open & Large Enclosure1.14A
Fl Amp @ 1-ph/ Size 1p/ Standard Enclosure1.14A
Fl Amp @ 3-ph/ Dp 20-30a/ Open & Large Enclosure1.13A
Fl Amp @ 3-ph/ Dp 20-30a/ Standard Enclosure1.09A
Fl Amp @ 3-ph/ Dp 40a/ Open & Large Enclosure1.18A
Fl Amp @ 3-ph/ Dp 40a/ Standard Enclosure1.15A
Fl Amp @ 3-ph/ Size 00,0,1/ Open & Large Enclosure1.06A
Fl Amp @ 3-ph/ Size 00,0,1/ Standard Enclosure1.03A
Full Load Amps1.02-1.27A
Sensing MethodMelting Alloy
Compatible Frame SizeB, S
Compatible With Grainger Part Number1H41, 1H411, 1H412, 1H413, 1H414, 1H415, 1H416, 1H417, 2BW14, 2BW2, 2BW21, 2BW22, 2BW23, 2BW25, 2BW31, 2BW35, 2BW7, 2PYD9, 2PYE6
Compatible With Manufacturer Model Number2510MBA1, 2510MBA2, 2510MBG1, 2510MBG2, 2510MBO1, 2510MBO2, 2510MBW1, 2510MBW11, 2510MBW12, 2510MBW2, 2510MCA1, 2510MCA2, 2510MCA3, 2510MCG1, 2510MCG2, 2510MCG3, 2510MCO3, 2510MCW1, 2510MCW11, 2510MCW13
Full Load Current0.91-1.03/0.94-1.06/0.94-1.07/0.95-1.05/0.97-1.11/0.98-1.12/0.99-1.13/1-1.1/1.03-1.14/1.04-1.19/1.06-1.21/1.11-1.26/1.16-1.23A
Nema Size0, 00, 1, 1P, 6
Overload Protection TypeMelting Alloy
Trip Class20

Shipping Info:

Ship weight (kg) 0.0225
Ship height (cm)2.01
Ship length (cm)5.79
Ship width (cm)2.79
HS code8538904000
Country of OriginMX

Product Variants

ProductModelFull Load AmpsFl Amp @ 3-ph/ Size 00,0,1/ Standard EnclosureFl Amp @ 3-ph/ Size 00,0,1/ Open & Large EnclosureFl Amp @ 1-ph/ Size 00,0,1/ Standard EnclosureFl Amp @ 1-ph/ Size 00,0,1/ Open & Large EnclosureFl Amp @ 1-ph/ Man. Size 1/ Open & Large EnclosureFl Amp @ 1-ph/ Man. Size 1/ Standard EnclosureFl Amp @ 1-ph/ Man. Size 0/ Standard EnclosurePrice
SQUARE D B0.44 Thermal Unit 0.30 - 0.38a | AF6PFH 1H594 B0.440.3-0.38A0.3A0.31A0.31A0.33A0.38A0.36A0.36A€52.46
SQUARE D B0.51 Thermal Unit 0.34 - 0.43a | AF6PFJ 1H595 B0.510.34-0.43A0.34A0.36A0.34A0.36A0.43A0.4A0.4A€52.46
SQUARE D B0.63 Thermal Unit 0.44 - 0.56a | AF6PFL 1H597 B0.630.44-0.56A0.44A0.46A0.45A0.48A0.56A0.52A0.52A€52.46
SQUARE D B0.71 Thermal Unit 0.53 - 0.63a | AF6PFM 1H598 B0.710.53-0.63A0.53A0.55A0.54A0.57A0.63A0.59A0.59A€52.46
SQUARE D B0.81 Thermal Unit 0.59 - 0.71a | AF6PFN 1H599 B0.810.59-0.71A0.59A0.61A0.61A0.64A0.71A0.66A0.66A€52.46
SQUARE D B0.92 Thermal Unit 0.64 - 0.78a | AF6PFP 1H600 B0.920.64-0.78A0.64A0.66A0.66A0.7A0.78A0.73A0.73A€52.46
SQUARE D B1.03 Thermal Unit 0.72 - 0.88a | AF6PHW 1H601 B1.030.72-0.88A0.72A0.75A0.73A0.77A0.88A0.81A0.81A€52.46
