SEALMASTER MSF-56 | BF8GZY

SEALMASTER MSF-56 Flange Bearing, 4 Bolt, 3 1/2 Inch Bore, Cast Iron, Set Screws, 8 7/16 Inch Length

Item: BF8GZY Model: MSF-56Cross Ref: 44A370
In Stock

Get it by Tuesday, Jun 10

€3,515.23 /unit
Add To Cart
Request a Quote

Payment

Delivery

Product Specifications:

Back Side To Center Width1.578"
Bearing Insert MaterialAlloy Steel
Bearing Insert TypeRadial Ball
Bore Diameter3 1/2"
Bore TypeCylindrical
ClosureDouble Sealed
Dynamic Load Capacity21566 lbf.
Expansion TypeFixed
Flange Thickness1"
Housing MaterialCast Iron
Housing Material FinishPowder Coated
Housing TypeSquare
Included BearingUCX17-56
IncludesSet Screw
Lubrication OpeningsOne Zirc Fitting
Maximum Speed2000 RPM
Mount Hole Center-to-center Height6 3/4"
Mount Hole Center-to-center Length6 3/4"
Overall Height8 7/16"
Overall Length8 7/16"
Overall Width3 25/32"
Seal MaterialFelt
Seal TypeTriple Lip
Self Lubricating BearingNo
Shaft Locking TypeSet Screws
Static Radial Load Capacity16301 lbf.

Shipping Info:

Ship weight (kg) 13.5
Ship height (cm)22.56
Ship length (cm)22.56
Ship width (cm)9.86
