Item | MIG Welder |
Color | Red |
Duty Cycle | 40% |
For Material Type | Mild Steel, Stainless Steel |
Material Thickness | 22 ga. to 1/2" |
Mild Steel Material Thickness | 22 ga. to 1/2" |
Model | K3068-1 |
Output Range | 30-300A |
Overall Depth | 38 4/5" |
Overall Height | 31 4/5" |
Overall Width | 18.9" |
Phase | 1 |
Portability | Wheeled Mounted |
Rated Output | 250A@26V DC |
Welded Material | Aluminum, Mild Steel, Stainless Steel |
Wire Type | Flux-Cored, Solid |
Amperage Range | 30-300A |
Application | Autobody, Farm, Light Industrial, Maintenance And Repair, Metal Fabrication |
For Maximum Material Thickness | 1/2" (Mild Steel), 5/16" (Stainless Steel) |
For Minimum Material Thickness | 16 ga. (Stainless Steel), 22 ga. (Mild Steel) |
For Wire Type | Flux Cored, Solid |
Includes | Dual Cylinder Mounting Kit, Gas regulator and hose kit for argon blend gases, Magnum PRO 250L MIG Gun, Work clamp and 10 ft. cable |
Input Frequency | 60 Hz |
Input Voltage | 208/230V AC |
Max. Wire Diameter | 0.045" (Flux-Cored), 3/64" (Solid) |
Maximum Amperage (mig) | 300A |
Maximum Wire Diameter - Flux-cored | 0.045" |
Maximum Wire Diameter - Solid | 0.047" |
Maximum Wire Feed Speed | 700 in./min. |
Merchandising Process | MIG, Flux Cored |
Minimum Amperage (mig) | 30A |
Minimum Wire Diameter | 0.025" (Mild Steel), 0.030" (Stainless Steel), 0.035" (Flux Cored) |
Minimum Wire Feed Speed | 50 in./min. |
Polarity | DC |
Power Cord Length | 10 ft. |
Process | MIG Welding (GMAW), Flux-Cored Welding (FCAW) |
Rated Output @ Duty Cycle (mig) | 250A @ 26V, 40% |
Remote Connection Type | 7 Pin (Lincoln) |
Weight | 220 lbs. |
Welder Series | Power MIG 256 Series |
Welding Power Source Type | CV |
