| Item | Electric Chain Hoist |
| Amperage Draw | 7.7A |
| Amps @ Low Volts | 7.7A |
| Body Depth | 11 5/8" |
| Body Finish | Enamel |
| Body Length | 22 3/16" |
| Body Material | Aluminum |
| Body Width | 15 19/32" |
| Brake Type | Pull Rotor Motor |
| Capacity | 1000 lbs. |
| Chain Finish | Nickel Plated |
| Chain Material | Alloy Steel |
| Classification | H4 |
| Clutch | Friction |
| Clutch Type | Friction Clutch |
| Color | Yellow |
| Configuration | Motorized Trolley |
| Control | Push Button Pendant |
| Control Cord | 11 ft. |
| Features | Extreme-Duty, Fan-Cooled Motor, Oil Bath-Lubricated, Heat-Treated Gearing, Pendant Plug-In Connections, Sealed Protection, Self-Adjusting MainteNaNce-Free Brake |
| Finish | Electrostatic Enamel |
| Fits Brand | Harrington Hoists Inc |
| For Max. Beam Height | Not Applicable |
| For Maximum Beam Flange Width | 5" |
| For Minimum Beam Flange Width | 2 9/32" |
| For Minimum Beam Height | 5 3/32" |
| For Outdoor Use | Yes |
| Headroom Size | 14 19/32" |
| Housing Depth | 11 5/8" |
| Housing Length | 22 3/16" |
| Includes | Chain Container, Drop Stops, Motorized Trolley, Rubber Bumpers, Trolley Brakes |
| Includes Brake | Brake Included |
| Includes Clutch | Clutch Included |
| Lift | 15 ft. |
| Lift Speed | 7 FPM |
| Lifting Hook Material | Carbon Steel |
| Lifting Hook Opening Width | 29/32" |
| Lifting Hook Type | Swivel Hook With Safety Latch |
| Load Capacity | 1000 lbs. |
| Lubrication | Oil Bath |
| Material | Die Cast Aluminum |
| Maximum Lift Speed | Not Applicable |
| Maximum Pulling Capacity | Not Applicable |
| Min. Between Hooks | 14 5/8" |
| Min. Radius Curve | 31 1/2" |
| Minimum Lift Speed | Not Applicable |
| Minimum Retracted Length | 14 19/32" |
| Motor Hp | 17/50 hp , 3/8 hp |
| Number Of Load Chains | 1 |
| Number Of Reeves | 1 |
| Number Of Speeds | 1 |
| Overload Protection Included | Yes |
| Phase | 1 |
| Reeving | 1 |
| Resistance Properties | Corrosion Resistant |
| Starts And Stops Per Hour | 360 |
| Thermal Protection | No |
| Trolley Speed | 40 FPM |
| Trolley Wheel Dia. | 3 3/4" |
| Trolley Wheel Material | Steel |
| Voltage | 115/230V |
| Chain Grade | Grade 80 |
| Controller Cord Length | 11 ft. |
| Controls | Push Button Pendant |
| Duty Classification | H4 - Heavy Duty |
| Fixed Lift Speed | 7 FPM |
| For Beam Flange Width | 2 9/32" to 5" |
| Headroom | 14 19/32" |
| Hoist Ip Rating | IP55 |
| Included Components | Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Rubber Bumpers, Safety Latch Hook |
| Lift Length | 15 ft. |
| Lifting Capacity | 1000 lbs. |
| Manufacturer's Warranty Length | 1 yr. |
| Max Current Draw | 7.7A |
| Minimum Radius Curve | 31 1/2" |
| Motor Horsepower | 3/8 hp |
| Mount Type | Motorized Trolley |
| Operating Voltage | 115/230V AC |
| Pendant Ip Rating | IP65 |
| Speed Programmability | Non-Programmable |
| Standards | ASME B30.16, ASME HST-1, NFPA 70 |
| Tonnage - Lifting Capacity | 0.5 ton. |
| Trolley Ip Rating | IP55 |
| Trolley Wheel Diameter | 3 3/4" |
