| Item | Sprinkler Pump |
| Amps | 5.2-5/2.5A |
| Bearing Type | Double Shielded Ball |
| Best Efficiency Flow | 26 GPM |
| Best Efficiency Flow Range @ Head | 38-11 GPM @ 46-85 Ft |
| Best Efficiency Flow Rate | 26 GPM |
| Best Efficiency Flow Rate @ Head | 26 GPM @ 46 ft. |
| Best Efficiency Head | 46 ft. |
| Case Pressure (maximum) | 150 psi |
| Compatible Discharge Pipe Size | 1 1/2" |
| Compatible Intake Pipe Size | 1 1/2" |
| Drain Plug | Yes |
| Duty | Continuous |
| Duty Cycle | Continuous |
| Flow Rate @ 10 Psi | 35 GPM |
| Flow Rate @ 15 Psi | 45 GPM |
| Flow Rate @ 2 Ft. | 52 GPM |
| Flow Rate @ 20 Psi | 26 GPM |
| Flow Rate @ 25 Psi | 34 GPM |
| Flow Rate @ 30 Psi | 26 GPM |
| Flow Rate @ 35 Psi | 15 GPM |
| For Media Type | Non-Flammable Liquids |
| For Use With | Nonflammable Liquids Compatible With Pump Component Materials |
| For Use With Potable Systems | No |
| Frame | 56J |
| Frequency | 60 Hz |
| Gpm Of Water @ 2 Ft. | 52 GPM |
| Height | 10 2/3" |
| Housing Material | Cast Iron |
| Housing Material - Pumps | Cast Iron |
| Hp | 3/4 hp |
| Hp - Pumps | 3/4 hp |
| Impeller Material | Stainless Steel |
| Impeller Type | Closed |
| Includes | Manual |
| Inlet Pressure | 111 psi |
| Inlet Size | 1 1/2" |
| Length | 17 1/3" |
| Max. Case Pressure | 150 psi |
| Max. Feet Of Head | 83 ft. |
| Max. Head | 83 ft. |
| Max. Pressure | 39 psi |
| Max. Pressure - Pumps | 39 psi |
| Max. Specific Gravity | 1 |
| Max. Suction Lift | 25 ft. |
| Media Type | Non Flammable Liquids |
| Min. Flow Rate | 35 GPM |
| Minimum Flow Rate | 35 GPM |
| Motor Ambient Temp. | 104°F |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Motor Frame Designation | 56J |
| Motor Type | Three Phase |
| No. Of Stages | 1 |
| Outlet Rotation | 90° |
| Outlet Size | 1 1/2" |
| Outlet Type | NPT |
| Overall Height | 10.69" |
| Overall Length | 17.31" |
| Overall Width | 8" |
| Overload Thermal Protection | Yes |
| Phase | 3 |
| Phase - Pumps | 3 |
| Port Rotation | 90 Deg. Increments |
| Pressure Pump Type | Sprinkler Pump |
| Pump Housing Material | Cast Iron |
| Rpm | 3450 RPM |
| Screw Material | Steel |
| Seal Application | Non-Flammable Liquids Compatible With Pump Components |
| Seal Material | Buna N, Carbon Ceramic, Stainless Steel , Buna N, Carbon, Ceramic, Stainless Steel |
| Seal Type | Mechanical |
| Self Priming | Yes |
| Service Factor | 1.5 |
| Shaft Material | Stainless Steel |
| Shut Off Length | 90 ft. |
| Shut Off Pressure (maximum) | 39 psi |
| Specific Gravity | 1 |
| Specific Gravity (maximum) | 1 |
| Stages | 1 |
| Suction Lift | 25 ft. |
| Suction Lift (maximum) | 25 ft. |
| Voltage | 208/230/460V AC |
| Volute Material | Cast Iron |
| Wetted Material | Buna N, Carbon Ceramic, Cast Iron, Stainless Steel , Buna N, Carbon, Cast Iron, Ceramic, Stainless Steel |
| Wetted Materials | Buna N, Carbon, Cast Iron, Ceramic, Stainless Steel |
| Width | 8" |
| Compatible With Media Type | Non-Flammable Liquids |
| Connection Type | NPT |
| Discharge Rotation | 90° Increments |
| Discharge Type | NPT |
| Feet Of Head (maximum) | 83 ft. |
| Flow Rate (minimum) | 35 GPM |
| Horsepower | 3/4 hp |
| Intake And Discharge Size | 1 1/2", 1 1/2" |
| Manufacturer Warranty Length | 1 yr. |
| Maximum Suction Lift | 25 ft. |
| Motor Ambient Temperature (maximum) | 104°F |
| Motor Enclosure | Totally Enclosed Fan Cooled |
| Nameplate Voltage | 208-230/460V AC |
| Priming | Self Priming |
| Rpm (maximum) | 3450 RPM |
| Shut Off Pressure | 39 psi |
| Standards | CSA |
| Thermal Overload Protection | Yes |
