SEALMASTER CRBFRS-PN208T RMW | BE2PQC

SEALMASTER CRBFRS-PN208T RMW

Item: BE2PQC Model: CRBFRS-PN208T RMWCross Ref: 713983
In Stock

Get it by Thursday, Jun 12

€371.13 /unit
Add To Cart
Request a Quote

Payment

Delivery

Product Specifications:

ItemFlange Bearing
Ability To RelubricateNo
Backside Shield/sealBackside Shield included loose in box
Bearing Insert FinishPhosphorus Nickel Coated
Bearing Insert MaterialSteel
Bearing Insert Material Grade52100
Bearing Insert TypeStandard Duty
Bolt Size1/2"
Bolt Spacing3 1/4"
Bore Dia.40 mm
Bore ShapeStraight
Cage MaterialPolyphenylene Sulfide
Cage TypeLand Riding Retainer
Dynamic Load Capacity7340 lbs.
End CapYes
Fixed Vs. ExpansionFixed
Foot Height14/25"
Grease Fitting Thread Size1/4"-28
Housing Backside Inner Diameter3 1/2"
Housing ColorSilver
Housing ConstructionOne Piece
Housing MaterialStainless Steel
Housing StyleFlange Block
Housing TypeFlange, Four Bolt
Htc8483.20.4040
Inner Race Heat Treat MethodZone Hardened
Inner Ring Outside Diameter2.07"
InsertSK-2555
Ip RatingIP69K
Length Through Bore1 49/64"
Locking Collar Outside Diameter2 3/4"
Lubrication TypeCalcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Max. Operating Temperature220°F
Max. Speed1750 RPM
Misalignment Capability-2° to +2°
Misalignment TypeStatic Only
OptionsCorrosion Resistant Reduced Maintenance Lubed for Life
Outer Ring Land ProfileTapered Lands
Overall Height1 13/16"
Overall Length5.13"
Overall Width5.13"
Pilot ConfigurationNo Pilot
Radial ClearanceStandard
Rolling ElementBall Bearing
Seal TypeMulti-Lip Contact Seal
Shaft Locking TypeConcentric
Size Code2-19
Static Load Rating4467 lbs.

Shipping Info:

Ship weight (kg) 2.475
Ship height (cm)5.41
Ship length (cm)13.97
Ship width (cm)13.97
