REES 04960-112 Mushroom Plunger Push-button, Shielded, Chrome | AX3LDA

REES 04960-112 Non Illuminated Push Button, 57mm Size, Momentary Push, Gray, 1NO/1NC

Item: AX3LDA Model: 04960-112Cross Ref: 53CW09
Limited Availability
€796.65 /unit
Request a Quote

Payment

Delivery

Product Specifications:

ItemNon-Illuminated Push Button
Contact Configuration#09 NO + NC
Cover ColorBlack
FeaturesEnclosed Gold Plated Contacts, Weatherproof Shield
Includes(4) Terminal Screws, Gasket, Metal Bezel, Plunger Head
LegendNo Legend
Nema Contact Rating DesignationA600/N300
Number Of Operators1
Operating Force3.8 lbs.
Operation TypeMomentary
Ac Contact Rating10A @ 600V
ActionMomentary
Bezel MaterialZinc Die Cast
Contact Form1NO/1NC
Dc Contact Rating1.1 A @ 250 V
Display Qty1
Head MaterialChrome Plated Steel
Head/lens ColorGray
Ip RatingIP66
Manufacturer Warranty Length1 yr.
Mechanical Operating Durability1 x 10^6
Mushroom Head Diameter57.15 mm
Nema Enclosure Rating4
Number Of Indicator Lights0
Operating Temperature - Maximum131°F
Operating Temperature - Minimum-22°F
Operator IlluminationNon Illuminated
Operator MaterialChrome Plated Steel
Operator Voltage Rating - Maximum600V AC
Overall Depth2.57"
Overall Height4.31"
Overall Width2.81"
Panel Mounting Hole Diameter57 mm
Product TypePush Button Operators
Push Button StyleMushroom Head
Resistance PropertiesImpact Resistant, Oil and Grease Resistant
StandardsANSI B11.1, CE, CSA C22.2 LR3648, IEC/EN 60947-5-5, OSHA, UL 508
Terminal ConnectionScrew Clamp

Shipping Info:

Ship weight (kg) 0.675
Country of OriginUS

Product Variants

ProductModelSizeOperating ForceCover ColorContact ConfigurationContact TypeOperation TypeSwitch ColorColorPrice
REES 00222-002 Mushroom Plunger, Plastic, Red-yellow | AX3KQN 00222-002-4.3 lbs.Yellow#66 NCSlow BreakMomentaryRed-€181.41
REES 00222-004 Mushroom Plunger, Plastic, Yellow-black | AX3KQP 00222-004-4.3 lbs.Black#66 NCSlow BreakMomentaryYellow-€181.41
REES 01307-012 Mushroom Plunger Switch, Metal, Chrome | AX3KRY 01307-012-9 lbs.Black#09 NO + NCSlow Make Slow BreakMomentary--€397.10
REES 01371-012 Mushroom Plunger Switch, Metal, Chrome, Black Cover | AX3KTB 01371-012-5.2 lbs.Black#09 NO + NCSlow Make Slow BreakMomentary--€224.66
REES 01371-112 Push-button, Mushroom Plunger, Chrome, Black | AX3KTC 01371-1122 1/4"5.2 lbs.Black#09 NO + NCSlow Make Slow BreakMomentary--€224.66
REES 01371-212 Push-button, Mushroom Plunger, Chrome, With Shield, Black | AX3KTD 01371-212-5.3 lbs.Black#09 NO + NCSlow Make Slow BreakMomentary--€237.37
REES 01371-312 Push-button, Mushroom Plunger, Chrome, With Shield, Zinc | AX3KTE 01371-312-5.3 lbs.Natural Zinc#63 NOSlow MakeMomentary--€237.37
