JOHNSON CONTROLS M9109-GGC-5 Proportional Actuator 80 Torque | AD4HGT 41P515

JOHNSON CONTROLS M9109-GGC-5 Proportional Actuator 80 Torque

Item: AD4HGT Model: M9109-GGC-5Cross Ref: 41P515
In Stock

Get it by Tuesday, Jun 17

Free Shipping Eligible. Free shipping is applicable on orders over €150 and products weighing less than 5 kg. Products exceeding 5 kg will incur the default shipping charges.

€377.34 /unit
Add To Cart
Request a Quote

Payment

Delivery

Product Specifications:

ItemElectric Actuator
Ambient Temp. Range125°F
Depth2 11/16" , 2.688"
Electrical ConnectionsSpade Terminal
For Shaft Dia.1/2"
For Shaft Height3/8"
For Shaft ShapeRound, Square
For Shaft Width3/8"
For Use With Building Automation SystemsBuilding Automation System Compatible
Height6"
IncludesAnti-Rotation Bracket
Mounting TypeDirect , Direct Mount
Number Of Auxiliary Switches2
Overall Depth2 3/4"
Overall Height6"
Overall Width4 1/4"
Power Consumption3.2 VA
Signal TypeProportional
Spring ReturnNo
Stroke Deg.90°
Switch TypeTwo Spdt
Time To Close60 sec.
Timing60 sec.
Torque80 lbs.-in.
TypeNon Spring Return
Width4 1/4"
ApplicationDamper And Valve
Contact FormSPDT
Control SignalProportional
Electrical Connection TypePlug In
For Shaft Diameter1/2"
Input Voltage24V AC
Ip RatingIP32
Maximum Operating Temperature131°F
Minimum Operating Temperature-4°F
Nema Rating2
Output Signal0-10V DC
Product TypeActuator
Rated Torque79.6 lbs.-in.
Return ActionNon-Spring Return
Shaft RotationCW/CCW
Shaft TypeSelf Centering Clamping
StandardsCE CERTIFIED
Stroke Degree90°
System ApplicationDampers, VAV Boxes

Shipping Info:

Ship weight (kg) 0.99
Ship height (cm)15.24
Ship length (cm)6.83
Ship width (cm)10.8
HS code8501104020
Country of OriginMX
