DAYTON 1LPV3 Dc Gearmotor 76 Rpm 12v Tenv | AB2EYP

DAYTON 1LPV3 Dc Gearmotor 76 Rpm 12v Tenv

Item: AB2EYP Model: 1LPV3
In Stock

Get it by Friday, Jun 13

Free Shipping Eligible. Free shipping is applicable on orders over €150 and products weighing less than 5 kg. Products exceeding 5 kg will incur the default shipping charges.

€383.50 /unit
Add To Cart
Request a Quote

Payment

Delivery

Product Specifications:

ItemDC Gearmotor
Bearing TypeBall On Motor , Porous Bronze Sleeve On Case, Ball On Motor
Brush TypeExternally Replaceable
Dimension A5.7"
FinishUnpainted
Full Load Amps2.1A
Gear CaseDie Cast Zinc
Gear Case MaterialDie Cast Zinc
Gear MaterialAcetyl, Steel , Hardened Steel, Phenolic
Gear Ratio2671 , 267:1
Gearmotor EnclosureTotally Enclosed Nonventilated
Gearmotor Mounting PositionAll Angle
Gearmotor Shaft OrientationParallel
Housing MaterialDie Cast Zinc
Input Hp1/15 hp , 1/30 hp
Insulation ClassClass F
Keyway Size TypeFlat
Keyway TypeFlat
Length Less Shaft5 5/8" , 5.63"
LubricationGrease Filled
Max. Ambient Temp.40°C
Motor EnclosureTotally Enclosed Non Ventilated , Totally Enclosed Nonventilated
Motor TypePermanent Magnet DC
MountingAll Position
Mounting OrientationAny Angle
Nameplate Rpm76 RPM
Output Shaft Dia.5/16"
Output Shaft Length3/4"
Overall Length6 3/8" , 6.38"
Overhung Load50 lbs.
Replaceable Motor BrushesYes
Reversible Shaft OutputNo
RotationReversible
Rpm Range76-100 RPM
ShaftSingle Output
Shaft Length3/4"
Shaft OrientationParallel
Tachometer FeedbackNo
Thermal ProtectionNone
Voltage12V DC
Full Load Current2.1A
Housing Material FinishUnpainted
Input Horsepower1/15 hp
Maximum Ambient Temperature40°C
Maximum Torque13 lbs.-in.
Nameplate Speed76 RPM
Operating Voltage12V DC
Output Shaft Diameter5/16"
Overhung Load Capacity50 lbs.-ft.
Seal TypeO-Ring Type on Output Shaft
StandardsC-UL RECOGNIZED, UL RECOGNIZED

Shipping Info:

Ship weight (kg) 2.097
Ship height (cm)14.48
Ship length (cm)31.75
Ship width (cm)14.22
HS code8501106060
Country of OriginUS
