CHAINFLEX CFBUS-PUR-056 Bus Cable, CFBUS-PUR, FireWire IEEE 1394a/b, PUR Jacket, Red, Shielded, 7 x OD | CQ8MDK

CHAINFLEX CFBUS-PUR-056 Bus Cable, CFBUS-PUR, FireWire IEEE 1394a/b, PUR Jacket, Red, Shielded, 7 x OD

Item: CQ8MDK Model: CFBUS-PUR-056Cross Ref: 801ME3
See variants (764)
In Stock
Check Availability

Get it by Tuesday, Jun 17

Flat Shipping at €24.99 + VAT €24.99 flat shipping is applicable on orders with an aggregate weight less than 10kg. Orders exceeding 10kg will be charged default shipping rates.

€12.24 /unit
Add To Cart
Request a Quote

Payment

Delivery

Product Specifications:

ItemCable
Bus SystemFirewire IEEE 1394A/B
Conductor Configuration(2) Pair 26 AWG (0.15)/(2) 22 AWG (0.38)
Conductor MaterialCopper
Impedance100 ohms
Includes GroundNo
Jacket ColorRed
Jacket MaterialPUR
LengthOrder By The Foot
Max. Acceleration98.4 m/sq. sec.
Max. Operating Temp.158°F
Maximum Velocity (supported)7 FPS
Maximum Velocity (unsupported)10 FPS
Min. Operating Temp. (fixed)-58°F
Min. Operating Temp. (flexible)-40°F
Minimum Bend Radius Factor (fixed)7 x OD
Minimum Bend Radius Factor (flexible)10 x OD
Minimum Bend Radius Factor E-chain12.5 x OD
Outside Dia.0.35"
Resistance PropertiesAntimicrobial, Oil And Grease Resistant, UV/Sunlight Resistant
ShieldingShielded
Voltage50V
Cable SeriesSeries CFBUS-PUR
Conductor Color CodeBlue, Red Black, Orange, Blue, White
Maximum Acceleration98.4 m/sq. sec.
Maximum Operating Temperature158°F
Maximum Velocity - Supported7 FPS
Maximum Velocity - Unsupported10 FPS
Minimum Bend Radius Factor - E-chain12.5 x OD
Minimum Bend Radius Factor - Fixed7 x OD
Minimum Bend Radius Factor - Flexible10 x OD
Minimum Operating Temperature - Fixed-58°F
Minimum Operating Temperature - Flexible-40°F
Product TypeBus Cable
Standards2011/65/EU (ROHS COMPLIANT-II), 2014/35/EU, CE 2014/35, TC RU C-DE. ME77.B.01218, VDW DESINA

Shipping Info:

Ship weight (kg) 0.0274
Ship height (cm)2.54
Ship length (cm)2.54
Ship width (cm)2.54
