| Item | General Digital Gauge |
| Accuracy | -0.5% to +0.5% |
| Accuracy Grade Gauge Type | Process |
| Adjustable Set Points | No |
| Application | Pneumatics, Hydraulics |
| Auto Shutoff | No |
| Backlit Screen | No |
| Basic Gauge Case Material | Plastic |
| Battery Included | Yes |
| Blowout Safety Back | No |
| Burst Pressure | 1600 psi |
| Calibration Certificate | No |
| Calibration Certificate Included | No |
| Case Color | Black |
| Case Depth | 1.61" |
| Case Dia. | 2 1/2" |
| Case Shape | Round |
| Connection Location | Bottom , Lower |
| Connection Size | 1/4" |
| Dial Size | 2 1/2" |
| Digit Height | 12/25" |
| Digital Gauge Display Units | Bar, Cmhg, Ft Wc, In Hg, Kpa, Mm Hg, Mpa, Psi |
| Digital Pressure And Vacuum Gauge Type | Digital Pressure Gauge |
| Display | LCD |
| Display Resolution | 0.01 psi |
| Features | Protective Boot |
| Gauge Connection Location | Bottom |
| Gauge Connection Size | 1/4" |
| Gauge Nominal Dial Size | 2 1/2" |
| Gauge Primary Range Units | Psi |
| Hazardous Location Rating | Not Rated |
| Includes | Batteries |
| Includes Rubber Boot | Yes |
| Keypad Material | Polycarbonate |
| Languages | English |
| Lens Material | Polycarbonate |
| Low-battery Indicator | Yes |
| Memory Features | Min/Max |
| Memory Storage | No |
| Mounting Hardware Included | No |
| Mounting Orientation | Upright Only |
| Nominal Dial Size | 2 1/2" |
| Non-sparking | No |
| Number Of Digits | 5 |
| Number Of Display Digits | 5 |
| Operating Temp. Range | -20°C to +60°C |
| Panel-mountable | No |
| Peak Hold | No |
| Power Source | Battery |
| Powered By | Battery |
| Pressure Range Type | Pressure |
| Process Connection Gender | Male |
| Process Connection Size | 1/4" |
| Range | 0 psi to 200 psi , 200 psi |
| Resolution | .01 psi |
| Rubber Boot Color | Black |
| Socket Material | Stainless Steel |
| Weatherproof | No |
| Accuracy Grade | ASME B40.7 Grade 2A |
| Ambient Operating Temperature Range | –20°F to 60°C, –4°F to 140°F |
| Auto-shutoff | No |
| Bar Graph | 20 Segments |
| Battery Run Time | 2000 hrs. |
| Battery Type | (2) AA Batteries |
| Case Construction | Welded Joint |
| Case Diameter | 2.5" |
| Case Material | Plastic |
| Compatible Process Media | Wide Variety Of Pressure Media |
| Display Range | 0 to 1.3789 Mpa, 0 to 1034.3 cm Hg, 0 to 10343 mm Hg, 0 to 1378.9 kPa, 0 to 13790 bar, 0 to 14.062 kg/sq cm, 0 to 200 psi, 0 to 407.2 in. Hg, 0 to 461.5 ft. H2O |
| Display Screen Type | LCD |
| Display Units | 5 Digit |
| Gauge Accuracy Grade | Grade 2A Process |
| Gauge Application | For Liquids & Gases |
| Gauge Case Material | ABS Polycarbonate |
| Gauge Wetted Parts | Stainless Steel |
| Includes Batteries | Yes |
| Includes Calibration Certificate | No |
| Includes Mounting Hardware | No |
| Ip/nema Rating | NEMA IP67 |
| Low Battery Indicator | Yes |
| Manufacturer Warranty Length | 1 yr. |
| Mounting Type | Stem Mount |
| Number Of Display Lines | 2 |
| Pressure Gauge Type | Industrial Pressure Gauge |
| Pressure Range | 0 psi to 200 psi |
| Primary Display Range | 0 to 200 |
| Primary Display Units | psi |
| Process Connection | 1/4" NPT Male |
| Process Connection Location | Bottom |
| Process Connection Type | NPT |
| Process Temperature Range | -4°F to +140°F |
| Sensor Material | 17-4 Stainless Steel |
| Sensor Type | CVD Strain Gauge |
| Series | DG25 Series |
| Shock Resistance | MIL-STD-20G, Method 213B, Test Condition K |
| Standards | CE CERTIFIED, UL 61010-1 |
| Temperature Error | 0.04%°F |
| Vibration Resistance | MIL-STD-20G, Method 201A |
| Wetted Parts Material | 316L Stainless Steel, 17-4 Stainless Steel |
