Washdown Motors (524 Products)

DAYTON

voltage hp frame material shaft dia. full load amps frequency nameplate speed mounting type Price
115/208-230V AC
3/4 hp
Stainless Steel
5/8"
7.6/3.8-4A
60 Hz
1745 RPM
Face
€899.83
115/208-230V AC
1 hp
Stainless Steel
5/8"
11.2/5.6-5.8A
60 Hz
1745 RPM
Face
€942.74
115/208-230V AC
1 1/2 hp
Stainless Steel
5/8"
14.8/7.4-7.6A
60 Hz
1745 RPM
Face
€1,193.20
208-230V AC
2 hp
Stainless Steel
5/8"
7.4-8.9A
60 Hz
3450 RPM
Face
€1,109.34
208-230V AC
2 hp
Stainless Steel
5/8"
8.5-9.9A
60 Hz
1745 RPM
Face
€1,160.82
115/208-230V AC
1/2 hp
Stainless Steel
5/8"
5/2.5-2.6A
60 Hz
1745 RPM
Face, Base
€1,090.49
115/208-230V AC
3/4 hp
Stainless Steel
5/8"
7.6/3.8-4A
60 Hz
1745 RPM
Face, Base
€941.30
115/208-230V AC
1 hp
Stainless Steel
5/8"
11.2/5.6-5.8A
60 Hz
1745 RPM
Face, Base
€984.04
115/208-230V AC
1 1/2 hp
Stainless Steel
5/8"
14.8/7.4-7.6A
60 Hz
1745 RPM
Face, Base
€1,081.22
208-230V AC
2 hp
Stainless Steel
5/8"
7.9-8.9A
60 Hz
3450 RPM
Face, Base
€1,123.44
MARATHON MOTORS

hp full load amps nameplate speed mounting type nominal efficiency motor mounting type length less shaft endshield finish Price
1 hp
12.8/6.4A
1725 RPM
Face, Base
75%
Face, Base
10 1/4"
Aluminum
€1,016.89
2 hp
20/10-10.2A
1740 RPM
Face, Base
80%
Face, Base
11 3/4"
Aluminum
€1,499.45
1 hp
12.8/6.4-6.6A
1725 RPM
Face
75%
Face
10 1/4"
Aluminum
€1,184.78
LEESON

voltage hp full load amps type amps full load torque frame length insulation class Price
90V
1/2 hp
5A
DN
5A
18 lbs.-in.
6.97"
Class F
€1,472.25
180V
1/2 hp
2.5A
DN
2.5A
18 lbs.-in.
7.47"
Class F
€1,183.47
90V
3/4 hp
7A
DN
7A
27 lbs.-in.
8.47"
Class F
€1,812.93
180V
3/4 hp
3.7A
DN
3.7A
27 lbs.-in.
7.97"
Class F
€1,720.31
90V
1 hp
10A
DF
10A
36 lbs.-in.
7.47"
Class F
€2,144.91
180V
1 hp
5A
DF
5A
36 lbs.-in.
7.47"
Class F
€2,174.68
180V
1 1/2 hp
7.6A
DF
7.6A
54 lbs.-in.
9.47"
Class H
€2,771.56
90V
1/4 hp
2.7A
DN
2.7A
9 lbs.-in.
4.47"
Class F
€1,264.73
90V
33/100 hp
3.5A
DN
3.5A
12 lbs.-in.
5.47"
Class F
€887.82
LEESON

full load amps mounting type shaft dia. speed type frame efficiency shaft length Price
1.9-1.8/0.9A
Round
0.562"
1700-1800 RPM
TN
71
76%
1.18"
€2,581.54
1.9-1.8/0.9A
Round
3/4"
1700-1800 RPM
TN
80
76%
1.57"
€1,486.02
1.9-1.8/0.9A
Rigid Base
3/4"
1700-1800 RPM
TN
80
76%
1.57"
€508.55
€2,781.90
2.3A
C Face Less Base
1800 RPM
IEC, Washdown
80
77%
€1,931.03
LEESON

voltage hp full load amps nominal efficiency type amps length less shaft full load torque Price
90V
1/4 hp
3.1A
67.5%
DN
3.1A
9 7/8"
9 lbs.-in.
€2,446.29
180V
33/100 hp
1.9A
73.7%
DN
1.9A
10 7/8"
12 lbs.-in.
€2,637.09
90V
1/2 hp
5.2A
79%
DF
5.2A
11 15/16"
18 lbs.-in.
€2,759.63
90V
3/4 hp
7.5A
86.2%
DF
7.5A
13 7/16"
27 lbs.-in.
€3,403.60
LEESON

hp full load amps type amps full load torque power frame length efficiency Price
1/3 hp
2.7A
U80-14
2.7A
12 lbs.-in.
0.37 kW
7 1/4"
71%
€633.40
1/2 hp
3.8A
U80-14
3.8A
18 lbs.-in.
0.55 kW
7 1/4"
77.3%
€661.51
3/4 hp
4.6A
X80-14
4.6A
27 lbs.-in.
0.75 kW
8 3/4"
84.2%
€602.97
1 hp
7.5A
Z80-14
7.5A
36 lbs.-in.
1.1 kW
9.62"
85.3%
€707.15
LEESON

voltage hp full load amps nominal efficiency type amps length less shaft full load torque Price
90V
1/4 hp
3.1A
67.5%
DN
3.1A
9 7/8"
9 lbs.-in.
€2,210.66
90V
33/100 hp
3.8A
74%
DN
3.8A
10 7/8"
12 lbs.-in.
€2,494.82
90V
1/2 hp
5.2A
79%
DF
5.2A
11 15/16"
18 lbs.-in.
€2,700.75
180V
1/2 hp
2.7A
73.7%
DF
2.7A
11 15/16"
18 lbs.-in.
€2,912.22
90V
1 hp
9.5A
81.6%
DF
9.5A
14 7/16"
36 lbs.-in.
€3,739.91
180V
1 hp
5A
85.3%
DF
5A
14 7/16"
36 lbs.-in.
€3,833.12
LEESON

voltage hp shaft dia. full load amps nameplate speed finish frequency nominal efficiency Price
208-230/460V
1/2 hp
5/8"
2A
1725 RPM
Epoxy Coating
60 Hz
74%
€835.17
208-230/460V
3/4 hp
5/8"
1.4A
1725 RPM
Epoxy Coating
60 Hz
77%
€1,071.94
208-230/460V
1 hp
5/8"
3.2/1.6A
1760 RPM
Epoxy Coating
60 Hz
85.5%
€1,521.71
230/460V
1 hp
7/8"
3.2/1.6A
1760 RPM
Unfinished
60 Hz
85.5%
€1,951.81
230/460V
2 hp
7/8"
2A
1745 RPM
Epoxy Coating
60 Hz
86.5%
€1,448.06
230/460V
1 1/2 hp
7/8"
2.4A
1750 RPM
Epoxy Coating
60 Hz
86.5%
€891.01
230/460V
3 hp
1 1/8"
7.8/3.9A
1760 RPM
Epoxy Coating
60 Hz
89.5%
€1,594.30
230/460V
5 hp
1 1/8"
12.6/6.3A
1760 RPM
Epoxy Coating
60 Hz
89.5%
€2,195.56
230/460V
5 hp
1 1/8"
12/6A
3515 RPM
Epoxy Coating
60 Hz
88.5%
€3,048.55
230/460V AC
7 1/2 hp
1 1/8"
8.8A
3500 RPM
Epoxy Coating
50/60 Hz
89.5%
€4,040.89
LEESON

voltage frequency hp shaft dia. finish mounting type full load amps nameplate speed Price
208-230/460V
60 Hz
1/2 hp
5/8"
Epoxy Coating
Rigid Base
1.9-2/1A
1800 RPM
€669.17
208-230/460V
60 Hz
3/4 hp
5/8"
Epoxy Coating
Rigid Base
2.8-2.7/1.4A
1800 RPM
€1,465.82
208-230/460V
60 Hz
33/100 hp
5/8"
Unfinished
Rigid Base
1.5-1.7/0.85A
1725 RPM
€723.20
208-230/460V
60 Hz
1/2 hp
5/8"
Epoxy Coating
Rigid Base
1.8A
1725 RPM
€969.66
208-230/460V
60 Hz
3/4 hp
5/8"
Epoxy Coating
Rigid Base
1.2A
1725 RPM
€772.43
230/460V
60 Hz
1 hp
5/8"
Epoxy Coating
Rigid Base
1.3A
3450 RPM
€983.15
230/460V
60 Hz
1 1/2 hp
5/8"
Epoxy Coating
Rigid Base
1.9A
3450 RPM
€1,327.19
208-230/460V
60 Hz
1/2 hp
5/8"
Epoxy Coating
Rigid Base
2.3/1.2A
1140 RPM
€1,313.13
208-230/460V
60 Hz
33/100 hp
5/8"
Epoxy Coating
€630.44
208-230/460V
60 Hz
1 hp
5/8"
Epoxy Coating
Rigid Base
3.2/1.6A
1760 RPM
€1,521.50
LEESON

hp shaft dia. full load amps nameplate speed nominal efficiency shaft length body dia. length less shaft Price
1/2 hp
5/8"
4.3A
1725 RPM
66%
1 22/25"
7.38"
8 9/16"
€1,049.86
1 hp
5/8"
6.4A
1725 RPM
75%
1 22/25"
7.38"
9 13/16"
€1,292.44
2 hp
1 1/8"
12.6A
1740 RPM
71%
2 3/4"
8.38"
10 5/8"
€2,600.47
LEESON

hp shaft dia. full load amps nameplate speed nominal efficiency shaft length amps motor mounting type Price
1/2 hp
5/8"
0.8A
1725 RPM
74%
1 22/25"
0.8A
Face, Base
€669.17
2 hp
7/8"
2.3A
1745 RPM
86.5%
2 1/4"
2.3A
Rigid Base
€2,058.55
LEESON

hp full load amps nameplate speed speed nominal efficiency no. of poles amps length less shaft Price
33/100 hp
3.1A
1725 RPM
1700-1800 RPM
62%
4
6.4/3.2A
8 7/16"
€1,028.64
1/2 hp
4.3A
1725 RPM
1700-1800 RPM
66%
4
8.8/4.4A
8 15/16"
€989.51
3/4 hp
5.4A
1725 RPM
1700-1800 RPM
70%
4
10.8/5.4A
9 11/16"
€727.69
1 hp
6.4A
1725 RPM
1700-1800 RPM
75%
4
12.8/6.4A
10 3/16"
€1,091.40
1/2 hp
7.6/3.8A
3450 RPM
3400-3600 RPM
63%
2
7.6/3.8A
8 7/16"
€932.33
3/4 hp
5A
3450 RPM
3400-3600 RPM
64%
2
10/5A
9 7/16"
€1,123.95
1 hp
6A
3450 RPM
3400-3600 RPM
70%
2
12/6A
9 15/16"
€1,034.57
1 1/2 hp
8.5A
3450 RPM
3400-3600 RPM
72%
2
17/8.5A
10 7/16"
€922.74
LEESON

voltage hp shaft dia. finish mounting type frequency full load amps nameplate speed Price
208-230/460V
3/4 hp
5/8"
Epoxy Coating
Round
60 Hz
1.2A
1725 RPM
€1,186.45
208-230/460V
3/4 hp
5/8"
Epoxy Coating
Round
60 Hz
1.1A
3450 RPM
€657.42
230/460V
1 hp
5/8"
Epoxy Coating
Round
60 Hz
1.3A
3450 RPM
€1,014.47
230/460V
1 1/2 hp
5/8"
Epoxy Coating
Round
60 Hz
1.9A
3450 RPM
€1,383.11
208-230/460V
1/2 hp
5/8"
Epoxy Coating
Round
60 Hz
1.8A
1725 RPM
€867.72
208-230/460V
1/4 hp
5/8"
Epoxy Coating
Round
60 Hz
1.1A
€788.90
208-230/460V
1/2 hp
5/8"
Epoxy Coating
Round
60 Hz
2A
1725 RPM
€1,042.88
208-230/460V
3/4 hp
5/8"
Epoxy Coating
Round
60 Hz
1.4A
1725 RPM
€971.02
208-230/460V
1 hp
5/8"
Epoxy Coating
Round
60 Hz
3.2/1.6A
1760 RPM
€920.61
208-230/460V
1 1/2 hp
5/8"
Epoxy Coating
Round
60 Hz
4.6-4.8/2.4A
1750 RPM
€947.49
LEESON

voltage hp frame material full load amps mounting type nominal efficiency shaft length end shield material Price
115/208-230V
33/100 hp
Rolled Steel
3.1A
Round
62%
1 22/25"
Cast Aluminum
€618.29
115/208-230V
1/2 hp
Rolled Steel
4.3A
Round
66%
1 22/25"
Cast Aluminum
€858.82
115/208-230V
1 hp
Rolled Steel
6.4A
Round
75%
1 22/25"
Cast Aluminum
€1,254.04
115/208-230V AC
1 1/2 hp
Stainless Steel
9.9A
Round
71%
1 7/8"
Aluminum
€1,065.21
115/208-230V
3/4 hp
Rolled Steel
5.4A
Face
70%
1 22/25"
Cast Aluminum
€1,097.51
LEESON

hp shaft dia. full load amps nameplate speed type shaft length amps power Price
1/2 hp
5/8"
1.6/0.8A
1800 RPM
TN
1 22/25"
1.6/0.8A
0.37 kW
€1,355.69
3/4 hp
5/8"
2.4-2.3/1.15A
1800 RPM
TN
1 22/25"
2.3/1.2A
0.56 kW
€877.72
1 hp
5/8"
3.2/1.6A
1760 RPM
TF
1 22/25"
3.2/1.6A
0.75 kW
€1,107.90
1 hp
7/8"
3.2/1.6A
1800 RPM
TF
2 3/25"
3.2/1.6A
0.75 kW
€1,107.90
2 hp
7/8"
6-5.8/2.9A
1800/1500 RPM
TF
2"
5.8/2.9A
1.5 kW
€2,386.38
LEESON

voltage hp shaft dia. full load amps nameplate speed type shaft length amps Price
208-230/460V
3/4 hp
5/8"
2.4-2.3/1.15A
1800/1725 RPM
TN
1 22/25"
2.3/1.2A
€885.27
208-230/460V
1 hp
5/8"
3.2/1.6A
1760 RPM
TF
1 22/25"
3.2/1.6A
€1,110.28
230/460V
2 hp
7/8"
5.8/2.9A
1800/1500 RPM
TF
2 1/4"
5.8-6/2.9A
€1,293.69
LEESON

voltage hp shaft dia. full load amps nameplate speed finish speed no. of poles Price
208-230/460V
3 hp
7/8"
8-8.8/4A
3490 RPM
Unfinished
3400-3600 RPM
2
€2,270.05
208-230/460V
3 hp
7/8"
7.8-8.4/3.9A
1770 RPM
Epoxy Coating
1700-1800 RPM
4
€2,758.26
208-230/460V
5 hp
7/8"
12-13.2/6A
3495 RPM
Epoxy Coating
3400-3600 RPM
2
€2,837.32
208-230/460V
5 hp
7/8"
12.6-13.8/6.3A
1760 RPM
Epoxy Coating
1700-1800 RPM
4
€1,993.73
208-230/460V
7 1/2 hp
7/8"
8.8A
3510 RPM
Epoxy Coating
3400-3600 RPM
2
€3,618.15
230/460V
7 1/2 hp
7/8"
19.6/9.8A
1765 RPM
Epoxy Coating
1700-1800 RPM
4
€2,683.90
230/460V
10 hp
1"
23.6/11.8A
3525 RPM
Epoxy Coating
3400-3600 RPM
2
€4,258.89
230/460V
10 hp
7/8"
26.4/13.2A
1760 RPM
Epoxy Coating
1700-1800 RPM
4
€3,072.13
LEESON

hp full load amps nameplate speed frequency speed nominal efficiency no. of poles shaft length Price
3 hp
7.8/3.9A
1770 RPM
60 Hz
1700-1800 RPM
89.5%
4
4 7/25"
€3,669.82
5 hp
12/6A
3495 RPM
60 Hz
3400-3600 RPM
88.5%
2
4.21"
€4,145.77
5 hp
12.6/6.3A
1760 RPM
60 Hz
1700-1800 RPM
89.5%
4
4.21"
€4,031.74
7 1/2 hp
18.6/9.3A
3525 RPM
60 Hz
3400-3600 RPM
89.5%
2
4.21"
€4,568.07
BALDOR MOTOR

voltage hp frame material shaft dia. full load amps finish type frame size Price
180V
1/4 hp
Steel
5/8"
1.3A
Unfinished
3413P
56C
€1,730.43
180V
1/2 hp
Stainless Steel
5/8"
2.5A
Unfinished
3428P
56C
€2,049.46
90V
1/2 hp
Stainless Steel
5/8"
5.2A
Unfinished
3428P
56C
€2,049.46
90V
1 hp
Stainless Steel
5/8"
9.6A
Unfinished
3536P
56C
€3,028.27
180V
1 hp
Stainless Steel
5/8"
4.9A
Unfinished
3536P
56C
€3,028.27
90V
1/3 hp
Steel
5/8"
3.2A
Epoxy Coating
3327P
56C
€1,525.98
180V
1/2 hp
Steel
5/8"
2.5A
Epoxy Coating
3336P
56C
€1,716.23
90V
1/2 hp
Steel
5/8"
9.5A
Epoxy Coating
3336P
56C
€1,812.11
180V
1 hp
Steel
5/8"
5A
Epoxy Coating
3435P
56C
€2,525.60
180V
1 1/2 hp
Steel
7/8"
7.7A
Epoxy Coating
3536P
145TC
€4,830.65
BALDOR MOTOR

voltage hp shaft dia. full load amps nameplate speed finish mounting type speed Price
230/460V
15 hp
1 5/8"
35.4/17.7A
1765 RPM
Unfinished
C Face, Foot Mounted
1700-1800 RPM
€10,122.00
230/460V
20 hp
1 5/8"
46.8/23.4A
1760/1765 RPM
Unfinished
C Face, Foot Mounted
1700-1800 RPM
€11,738.29
208-230/460V
15 hp
1 5/8"
33-36/16.5A
3520 RPM
Unfinished
C Face, Foot Mounted
3400-3600 RPM
€10,284.42
230/460V
1 hp
5/8"
1.4A
3450 RPM
Unpainted
C Face, Foot Mounted
3450 RPM
€2,286.63
208-230/460V
1 hp
5/8"
1.5A
1745/1770 RPM
Unfinished
C Face, Foot Mounted
1745 RPM
€2,277.76
208-230/460V
1 hp
7/8"
3.3-3/1.5A
1760 RPM
Unfinished
C Face, Foot Mounted
1700-1800 RPM
€2,311.24
575V
1 hp
7/8"
1.25A
1765 RPM
Unfinished
C Face, Foot Mounted
1700-1800 RPM
€2,311.24
208-230/460V
1 1/2 hp
5/8"
3.7-3.6/1.8A
3500 RPM
Unfinished
C Face, Foot Mounted
3400-3600 RPM
€2,300.40
208-230/460V
1 1/2 hp
7/8"
3.7-3.6/1.8A
3500 RPM
Unfinished
C Face, Foot Mounted
3400-3600 RPM
€2,319.11
208-230/460V
1 1/2 hp
5/8"
2.2A
1760 RPM
Unfinished
C Face, Foot Mounted
1760 RPM
€2,321.08
BALDOR MOTOR

voltage hp shaft dia. full load amps nameplate speed mounting type speed no. of poles Price
208-230/460V
1 hp
5/8"
1.7A
1770 RPM
Rigid Base
1700-1800 RPM
4
€2,390.81
208-230/460V
1 hp
7/8"
1.5A
1760 RPM
C Face, Foot Mounted
1760 RPM
4
€1,823.99
208-230/460V
1 1/2 hp
5/8"
2.1A
1755/1770 RPM
C Face, Foot Mounted
1755 RPM
4
€1,902.74
208-230/460V
1 1/2 hp
7/8"
4.4-4.2/2.1A
1755/1770 RPM
C Face, Foot Mounted
1700-1800 RPM
4
€1,952.93
208-230/460V
2 hp
7/8"
5-5.4/2.5A
3450 RPM
C Face, Foot Mounted
3400-3600 RPM
2
€2,313.20
208-230/460V
2 hp
5/8"
2.9A
1750 RPM
C Face, Foot Mounted
1750 RPM
4
€2,251.19
208-230/460V
2 hp
7/8"
5.6-5.9/2.8A
1755 RPM
C Face, Foot Mounted
1700-1800 RPM
4
€2,396.88
208-230/460V
3 hp
7/8"
7.2-7.8/3.6A
3470/3475 RPM
C Face, Foot Mounted
3400-3600 RPM
2
€2,846.72
208-230/460V
3 hp
1 1/8"
8-8.1/4A
1760 RPM
C Face, Foot Mounted
1700-1800 RPM
4
€2,932.35
208-230/460V
5 hp
1 1/8"
11.4-12.4/5.7A
3480 RPM
C Face, Foot Mounted
3400-3600 RPM
2
€3,609.58
BALDOR MOTOR

voltage hp shaft dia. full load amps nameplate speed nominal efficiency type amps Price
208-230/460V
1/2 hp
5/8"
1.9-1.8/0.9A
1765/1770 RPM
84%
3516M
1.9-1.8/0.9A
€3,251.66
230/460V
3/4 hp
5/8"
2.28/1.14A
1750/1765 RPM
84%
3517M
2.28/1.14A
€3,513.90
208-230/460V
1 hp
5/8"
3-2.9/1.45A
1770 RPM
85.5%
3524M
3-2.9/1.45A
€3,606.66
208-230/460V
1 hp
7/8"
3-2.9/1.45A
1745/1770 RPM
85.5%
3524M
3-2.9/1.45A
€3,536.61
208-230/460V
1 1/2 hp
7/8"
4.4-4.2/2.1A
1755/1770 RPM
86.5%
3533M
4.4-4.2/2.1A
€3,924.73
208-230/460V
2 hp
7/8"
6-5.8/2.9A
1755/1760 RPM
86.5%
3530M
6-5.8/2.9A
€3,993.83
208-230/460V
3 hp
1 1/8"
9-8.4/4.2A
1760 RPM
89.5%
3631M
9-8.4/4.2A
€4,832.55
208-230/460V
5 hp
1 1/8"
13.9-13.4/6.7A
1750 RPM
89.5%
3642M
13.9-13.4/6.7A
€5,837.86
BALDOR MOTOR

voltage hp shaft dia. nameplate speed full load amps mounting type speed no. of poles Price
208-230/460V
7 1/2 hp
1 5/8"
1180 RPM
22-23/11A
C Face, Foot Mounted
1100-1200 RPM
6
€6,018.67
208-230/460V
10 hp
1 5/8"
1180 RPM
30.2-30.6/15.1A
C Face, Foot Mounted
1100-1200 RPM
6
€6,841.29
230/460V
15 hp
1 5/8"
1765 RPM
36/18A
C Face, Foot Mounted
1700-1800 RPM
4
€8,062.43
208-230/460V
20 hp
1 5/8"
1765 RPM
48-52/24A
C Face, Foot Mounted
1700-1800 RPM
4
€9,349.86
230/460V
15 hp
1 5/8"
3500 RPM
33.2/16.6A
C Face, Foot Mounted
3400-3600 RPM
2
€8,191.17
230/460V
1 hp
5/8"
3450 RPM
3400-3600 RPM
2
€1,619.68
208-230/460V
1 hp
5/8"
1770 RPM
1.7A
Rigid Base
1700-1800 RPM
4
€2,093.47
208-230/460V
1 hp
7/8"
1745/1770 RPM
3-2.9/1.45A
C Face, Foot Mounted
1700-1800 RPM
4
€1,660.39
208-230/460V
1 1/2 hp
5/8"
3500 RPM
2A
Rigid Base
3400-3600 RPM
2
€2,118.33
208-230/460V
1 1/2 hp
5/8"
1755/1770 RPM
2.1A
C Face, Foot Mounted
1755 RPM
4
€1,702.04
BALDOR MOTOR

hp frame material shaft dia. nameplate speed finish full load amps nominal efficiency type Price
15 hp
Steel
1 5/8"
1765 RPM
Epoxy Coating
14.5A
92.4%
3942M
€8,062.43
20 hp
Steel
1 5/8"
1765 RPM
Epoxy Coating
19A
93%
3952M
€9,349.86
1 hp
Steel
5/8"
1745 RPM
Epoxy Coating
1.2A
85.5%
3524M
€1,627.25
1 1/2 hp
Steel
7/8"
1755 RPM
Epoxy Coating
1.7A
86.5%
3533M
€1,738.01
2 hp
Steel
7/8"
1755/1764 RPM
Epoxy Coating
2.4A
86.5%
3530M
€1,915.98
3 hp
Steel
1 1/8"
1760 RPM
Epoxy Coating
89.5%
3631M
€2,516.14
5 hp
Steel
1 1/8"
1750 RPM
Epoxy Coating
5.3A
89.5%
3642M
€2,851.24
7 1/2 hp
Steel
1 3/8"
1770 RPM
Epoxy Coating
7.6A
91.7%
3736M
€3,606.66
10 hp
Steel
1 3/8"
1770 RPM
Epoxy Coating
9.6A
91.7%
3752M
€4,099.85
1/2 hp
Stainless Steel
5/8"
1755 RPM
Unfinished
0.7A
80%
3513M
€2,165.56
BALDOR / DODGE

voltage hp full load amps nameplate speed speed no. of poles synchronous speed service factor Price
208-230/460V
1/3 hp
1.1-1.2/0.55A
3450 RPM
3450 RPM
2
3600 RPM
1.15
€1,708.83
208-230/460V
1/2 hp
1.9-1.8/0.9A
3450 RPM
3400-3600 RPM
2
3600 RPM
1.15
€2,017.91
208-230/460V
1/2 hp
1.82-1.98/0.91A
1755 RPM
1700-1800 RPM
4
1800 RPM
1.25
€2,165.56
230/460V
3/4 hp
2.2/1.1A
3450 RPM
3400-3600 RPM
2
3600 RPM
1.25
€2,085.82
208-230/460V
3/4 hp
2.16-2.36/1.08A
1740/1745 RPM
1700-1800 RPM
4
1800 RPM
1.25
€2,241.35
BALDOR MOTOR

hp full load amps nameplate speed mounting type speed nominal efficiency no. of poles type Price
1/2 hp
3.5A
1740 RPM
Rigid Base
1700-1800 RPM
68%
4
3520L
€1,306.13
3/4 hp
10.6/5.3A
1725 RPM
C Face, Foot Mounted
1700-1800 RPM
66%
4
3524L
€1,181.40
1 hp
11.8/5.9A
3450 RPM
C Face, Foot Mounted
3400-3600 RPM
68%
2
3520L
€1,106.61
1 hp
11.8/5.9A
1725 RPM
C Face, Foot Mounted
1700-1800 RPM
70%
4
3528L
€1,357.46
1 1/2 hp
16/8A
3450 RPM
C Face, Foot Mounted
3400-3600 RPM
70%
2
3524L
€1,366.93
1 1/2 hp
12.4/6.2A
1725 RPM
C Face, Foot Mounted
1700-1800 RPM
80%
4
3532LC
€1,625.37
BALDOR MOTOR

voltage hp shaft dia. full load amps nameplate speed speed insulation class service factor Price
208-230/460V
1 hp
5/8"
1.5A
1745/1770 RPM
1745 RPM
Class F
1.15
€1,410.48
208-230/460V
1 hp
7/8"
3-2.9/1.45A
1745/1770 RPM
1700-1800 RPM
Class F
1.15
€1,444.55
208-230/460V
1 1/2 hp
7/8"
4.4-4.2/2.1A
1755/1770 RPM
1700-1800 RPM
Class H
1
€1,588.45
208-230/460V
2 hp
7/8"
6-5.8/2.9A
1755/1760 RPM
1700-1800 RPM
Class F
1.15
€2,438.28
208-230/460V
3 hp
1 1/8"
9-8.4/4.2A
1760 RPM
1700-1800 RPM
Class F
1.15
€2,326.81
208-230/460V
5 hp
1 1/8"
13.9-13.4/6.7A
1750 RPM
1700-1800 RPM
Class F
1.15
€2,648.66
230/460V
7 1/2 hp
1 3/8"
18.8/9.4A
1770 RPM
1700-1800 RPM
Class F
1.15
€3,315.10
230/460V
10 hp
1 3/8"
24/12A
1770 RPM
1700-1800 RPM
Class F
1.15
€3,611.39
230/460V
1/2 hp
5/8"
1.6/0.8A
1740/1770 RPM
1700-1800 RPM
Class F
1.25
€968.41
230/460V
3/4 hp
5/8"
2.8/1.4A
1750/1765 RPM
1700-1800 RPM
Class F
1.25
€1,034.66
BALDOR MOTOR

voltage hp shaft dia. full load amps nameplate speed type frame size frame Price
208-230/460V
1/2 hp
5/8"
1.7-1.6/0.8A
1750 RPM
3515M
56C
56C
€2,514.01
208-230/460V
3/4 hp
5/8"
2.36-2.16/1.08A
1740/1745 RPM
3519M
56C
56C
€2,846.72
208-230/460V
1 hp
5/8"
3-2.9/1.45A
1745/1770 RPM
3524M
56C
56C
€2,954.99
230/460V
1 hp
7/8"
2.9/1.45A
1745/1770 RPM
3524M
143TC
143TC
€2,954.99
230/460V
1 1/2 hp
5/8"
4.2/2.1A
1760 RPM
3533M
56C
56C
€3,160.73
230/460V
1 1/2 hp
7/8"
4.2/2.1A
1760 RPM
3533M
145TC
145TC
€3,160.73
230/460V
2 hp
5/8"
5.8/2.9A
1750 RPM
3528M
56C
56C
€3,376.30
230/460V
2 hp
7/8"
2.9A
1750 RPM
3528M
145TC
145TC
€3,376.30
230/460V
3 hp
1 1/8"
8.4/4.2A
1760 RPM
3635M
182TC
182TC
€3,702.11
230/460V
5 hp
1 1/8"
13/6.5A
1750 RPM
3646M
184TC
184TC
€4,308.47
BALDOR MOTOR

voltage hp shaft dia. full load amps nameplate speed speed frame size magnetizing amps Price
230/460V
1/2 hp
5/8"
1.8/0.9A
1765/1770 RPM
1700-1800 RPM
56C
1.4/0.7A
€2,493.34
230/460V
3/4 hp
5/8"
2.2/1.1A
1740 RPM
1700-1800 RPM
56C
1.2/0.6A
€2,832.94
230/460V
1 hp
5/8"
3-2.9/1.45A
1745/1770 RPM
1745 RPM
56C
1.8/0.9A
€2,940.23
208-230/460V
1 hp
7/8"
3-2.9/1.45A
1770 RPM
1700-1800 RPM
143TC
1.8/0.9A
€2,940.23
230/460V
1 1/2 hp
5/8"
4.2/2.1A
1760 RPM
1700-1800 RPM
56C
2.4/1.2A
€3,144.97
230/460V
1 1/2 hp
7/8"
4.2/2.1A
1760 RPM
1700-1800 RPM
145TC
2.4/1.2A
€3,144.97
230/460V
2 hp
5/8"
5.8/2.9A
1750 RPM
1700-1800 RPM
56C
3.4/1.7A
€3,348.73
230/460V
2 hp
7/8"
5.8/2.9A
1750 RPM
1700-1800 RPM
145TC
3.4/1.7A
€3,348.73
230/460V
3 hp
1 1/8"
8.4/4.2A
1760 RPM
1700-1800 RPM
182TC
4.6/2.3A
€3,520.99
230/460V
5 hp
1 1/8"
13/6.5A
1750 RPM
1700-1800 RPM
184TC
5.8/2.9A
€4,103.72
BALDOR MOTOR

hp shaft dia. full load amps nameplate speed type frame size wire size magnetizing amps Price
7 1/2 hp
1 5/8"
18.2/9.1A
1765/1770 RPM
3940M
254TC
12 AWG
2A
€6,440.85
10 hp
1 5/8"
24/12A
1765 RPM
3956M
254TC
12 AWG
8.8/4.4A
€6,559.19
1 hp
7/8"
2.9/1.45A
1745/1770 RPM
3524M
143TC
18 AWG
1.8/0.9A
€2,417.69
1 1/2 hp
7/8"
4.2/2.1A
1755/1770 RPM
3533M
145TC
18 AWG
2.4/1.2A
€2,662.86
2 hp
1 1/8"
5.8/2.9A
1725/1760 RPM
3628M
182TC
16 AWG
3.4/1.7A
€3,139.02
3 hp
1 1/8"
8.2/4.1A
1760 RPM
3640M
184TC
16 AWG
4.2/2.1A
€3,195.82
5 hp
1 3/8"
13.4/6.7A
1760/1770 RPM
3732M
213TC
14 AWG
7/3.5A
€3,616.11
BALDOR MOTOR

voltage hp full load amps speed high voltage full load amps service factor power factor motor type Price
208-230/460V
1 hp
1.6A
3450 RPM
1.6A
1.4
74
3520M
€1,639.57
208-230/460V
1 1/2 hp
2A
3450 RPM
2A
1.3
84
3526M
€1,731.38
230/460V
2 hp
2.5A
3450 RPM
2.5A
1.2
88
3526M
€1,923.56
208-230/460V
3 hp
3.5A
3450 RPM
3.5A
1.15
92
3540M
€2,280.43
BALDOR MOTOR

voltage hp shaft dia. full load amps nameplate speed speed no. of poles frame size Price
230/460V
15 hp
1 3/4"
18A
1765 RPM
1765 RPM
4
254JM
€8,297.20
230/460V
20 hp
1 3/4"
24A
1765 RPM
1765 RPM
4
256JM
€9,588.41
208-230/460V
1 hp
7/8"
1.5A
1745/1770 RPM
1745 RPM
4
143JM
€1,778.72
208-230/460V
1 1/2 hp
7/8"
2A
3500 RPM
3500 RPM
2
143JM
€1,788.18
208-230/460V
1 1/2 hp
7/8"
2.1A
1755/1770 RPM
1755 RPM
4
145JM
€1,858.23
208-230/460V
2 hp
7/8"
2.5A
3490 RPM
3400-3600 RPM
2
143JM
€1,951.95
208-230/460V
2 hp
7/8"
2.9A
1755/1760 RPM
1755 RPM
4
145JM
€2,034.31
230/460V
3 hp
7/8"
3.6A
3450 RPM
3450 RPM
2
143JM
€2,383.61
230/460V
3 hp
7/8"
4.2A
1760 RPM
1760 RPM
4
182JM
€2,583.49
208-230/460V
5 hp
7/8"
5.6A
3430/3450 RPM
3400-3600 RPM
2
184JM
€3,145.64
BALDOR MOTOR

voltage hp shaft dia. full load amps nameplate speed mounting type speed no. of poles Price
230/460V
1 hp
5/8"
1.5A
1760/1770 RPM
C Face, Footless
1760 RPM
4
€1,655.65
208-230/460V
1 hp
7/8"
3.1-3/1.5A
1760/1770 RPM
C Face, Footless
1700-1800 RPM
4
€1,667.96
208-230/460V
1 1/2 hp
7/8"
4.5-4.4/2.2A
1760 RPM
C Face, Footless
1700-1800 RPM
4
€1,789.13
208-230/460V
1/2 hp
5/8"
1.9-1.8/0.9A
1765/1770 RPM
C Face, Footless
1765 RPM
4
€1,352.74
230/460V
3/4 hp
5/8"
2.28/1.14A
1750/1765 RPM
C Face, Footless
1750 RPM
4
€1,489.05
208-230/460V
1 hp
5/8"
1.7A
1770 RPM
Face
1700-1800 RPM
4
€2,097.35
208-230/460V
1 hp
7/8"
1.7A
1770 RPM
Face
1700-1800 RPM
4
€2,202.18
208-230/460V
1 1/2 hp
5/8"
4.4-4.2/2.1A
1755/1770 RPM
C Face, Footless
1700-1800 RPM
4
€1,730.43
208-230/460V
1 1/2 hp
7/8"
4.4-4.2/2.1A
1755/1770 RPM
C Face, Footless
1700-1800 RPM
4
€1,744.64
208-230/460V
2 hp
5/8"
2.8A
1760 RPM
Face
1700-1800 RPM
4
€2,428.76
BALDOR MOTOR

hp shaft dia. full load amps nameplate speed finish mounting type nominal efficiency type Price
1 hp
5/8"
1.7A
1770 RPM
White Epoxy Paint
Face
85.5%
3524M
€2,310.04
1 1/2 hp
5/8"
4.4-4.2/2.1A
1755/1770 RPM
Unfinished
C Face, Footless
86.5%
3533M
€1,932.27
1 1/2 hp
7/8"
4.4-4.2/2.1A
1755/1770 RPM
Unfinished
C Face, Footless
86.5%
3533M
€1,932.27
2 hp
7/8"
5.6-5.9/2.8A
1755 RPM
Unfinished
C Face, Footless
88.5%
3536M
€2,205.92
BALDOR MOTOR

hp full load amps nameplate speed mounting type nominal efficiency type amps full load torque Price
1/2 hp
3.5A
1740 RPM
Face
68%
3520L
7.4/3.7A
1.51 lbs.-ft.
€1,277.54
3/4 hp
10.6/5.3A
1725 RPM
C Face, Footless
66%
3524L
10.6/5.3A
2.24 lbs.-ft.
€1,142.59
1 hp
11.8/5.9A
1725 RPM
C Face, Footless
70%
3528L
11.8/5.9A
2.99 lbs.-ft.
€1,308.25
1 1/2 hp
12.4/6.2A
1725 RPM
C Face, Footless
80%
3532LC
12.4/6.2A
4.48 lbs.-ft.
€1,569.51
BALDOR MOTOR

hp shaft dia. full load amps speed motor lead quantity/wire size voltage @ frequency high voltage full load amps locked bearing indicator Price
1/2 hp
5/8"
3.7A
1725 RPM
6 @ 18 AWG
115V @ 60 Hz, 230V @ 60 Hz
3.7A
No Locked Bearing
€969.35
3/4 hp
5/8"
5.5A
1725 RPM
6 @ 18 AWG
115V @ 60 Hz, 230V @ 60 Hz
5.5A
No Locked Bearing
€1,135.01
1 hp
5/8"
6.4A
1725 RPM
6 @ 18 AWG
115V @ 60 Hz, 230V @ 60 Hz
6.4A
No Locked Bearing
€1,312.04
1 1/2 hp
7/8"
6.2A
1725 RPM
4 @ 16 AWG, A&J
230V @ 60 Hz
6.2A
Locked Bearing
€1,565.30
BALDOR / DODGE

MPN Price
CSSWDM3534
€1,673.46
BALDOR MOTOR

MPN Price
WDM3561TP
€2,268.12
WEG

MPN Price
01018ET3EHW215TC-S
€3,032.63
WEG

MPN Price
.7518NT3EHW56CZ
€813.32
WEG

MPN Price
1311087152
€2,069.49
WEG

MPN Price
00118NT3EHWR143TCZ
€937.59
WEG

MPN Price
00536EP3ESS184TCFL
€1,290.30
WEG

MPN Price
00118NT3EHW56CZFL
€920.64
WEG

MPN Price
H311007112
€5,814.89
LEESON

MPN Price
119489.00
€2,614.07
LEESON

MPN Price
117902.00
€568.69
LEESON

MPN Price
122030.00
€616.25
1 2

Description

Washdown motors are commonly used on conveyors in food packaging and processing industries, wet and humid environments or where regular machine cleaning is required. Raptor Supplies offers a wide variety of washdown motors from brands like Leeson, Baldor, Marathon Motors and Dayton. These washdown motors feature a totally enclosed design which protects internal components from dust and airborne contaminants. Speed of these motors ranges between 1075 and 3515 rpm. Baldor motors are designed for applications in residential HVAC systems, pumps and farm equipment. These motors are coated with Exxon Polyrex EM grease to provide resistance to rust & washout and for higher shear stability. Dayton washdown motors can be operated up to an ambient temperature of 40 degrees C to sustain harsh environmental conditions and are equipped with ball bearings for enhancing motor performance by reducing friction. Choose from a wide range of these washdown motors, available in single and triple phases on Raptor Supplies.

Working Mechanism

  • The washdown motor functions in a manner akin to a typical electric motor. Upon receiving electrical power, it initiates the rotation of its shaft, capable of propelling a range of mechanical apparatus, including pumps, conveyors or mixers.
  • Following the operation, the motor can undergo comprehensive cleaning procedures employing high-pressure washdown machinery or sterilising agents. The motor's engineering guarantees its resilience to endure these cleaning processes without incurring damage.

Features

Leeson Premium Duck Washguard Motors:

  • They feature stainless steel motors providing exceptional resistance to corrosion in wet environments.
  • These Leeson washdown motors are available in three-phase, single-phase and DC washdown duty motors, allowing users to select the exact motor configuration.
  • They are equipped with a rigid base and allow C face mounting for simplifying the integration of motors into various industrial setups, ensuring a seamless fit.
  • These washdown motors are equipped with double lip contact seals and V-ring seals, ensuring that water and contaminants are effectively kept out of the motor.

Dayton <a href="/p/dayton/washdown-motor">Washdown Motors</a>:

  • These washdown motors are totally enclosed to protect internal components from dust and moisture.
  • They have standard / 303 / 300 Series stainless steel shafts for strength and resist corrosion.
  • These motors are equipped with ball bearings for reducing friction and are capable of being operated up to an ambient temperature of 40 degrees C.
  • They are available in capacitor-start, permanent split capacitor and 3-phase motor configurations.

Frequently Asked Questions

Q. What factors should I consider when selecting a washguard motor for my application?

A. Major factors include the motor's power requirements (three-phase, single-phase, or DC), the specific environmental conditions (moisture level, contaminants), mounting options (rigid base or C face) and the required horsepower to ensure optimal performance in your application.

Q. What maintenance is required for washguard motors to ensure their longevity?

A. Regular maintenance includes inspecting seals for wear or damage and replacing them if necessary. Ensure that the motor's housing remains intact and free from corrosion. Lubricate bearings and check for loose connections.

Q. Are Lesson washdown motors shockproof?

A. Yes, Leeson Premium Duck washguard motors are equipped with an inverter-rated insulation system (IRIS) which is a specialised insulation system designed for alternating current (AC) applications, particularly for electric motors or other electrical equipment used in conjunction with inverters. This insulation system is engineered to withstand the unique challenges posed by the use of inverters in AC designs.

Popular Search Queries

Explore More
